Innovate Optronics(GZ)Co.,Ltd specialize in sales of all Innolux lcd panels and modules,we have sufficient inventory and favorable prices.

We can also customize products according to customer's requirements.Customized touch screen,high brightness backlight,various interfaces,housing etc.We has focused on LCD panel industry for more than 20 years,we can provide customers with perfect and professional LCD solutions.

Product Features&Specifications：

Type: TFT lcd display module

Display Size: 10.1 inch

Supplier Type: Special dealer of manufacturer

Place of Origin:Hong Kong, China

Brand Name: Innolux

Product Name: Innolux lcd panel EJ101IA-01G.

Display Mode: IPS, Normally Black, Transmissive

Luminance: 350 cd/m2(Typ.)

Viewing Angle: 85/85/85/85 (Typ.)(CR≥10)

Driver IC: /

Touch panel: Without

Interface Type: LVDS

Rohs: Yes

Resolution: 1280X 3(RGB)X 800

PPI (Pixel per inch): 150

Module Size(mm): 229.46 x 149.1 x 2.5mm

Active Area: 216.96 x 135.6 mm

Dot Pitch(mm): 0.0565(W) X 0.1695(H)

Surface Treatment: Hard Coating

Viewing Angle (Tpy.)θT/θB/θL/θR: 85/85/85/85

Viewing Direction: Free

NTSC: 50%

Luminance/nits.center: 350

Contrast Ratio: 800

Response Time/ms.25℃ (typ.): 25ms

Consumption (W): 2.460

Weight (g): 183.0

Interface: 40pin Connector(LVDS)

Operation Temperature( ℃): 0~50

Storage Temperature (℃): -20~60

HTHH.(op): 40℃, 90%RH

Status: MP

EJ101IA-01G is a 10.1-inch LCD module product launched by Innolux using a-Si TFT-LCD technology. It is equipped with WLED backlight, no backlight drive, no touch, and has been equipped with ILI6192+ILI5801 driver ICs.

EJ101IA-01G display resolution is 1280 (RGB) × 800 (WXGA), with a aspect ratio of 16:10 (width: height), and pixels arranged in RGB vertical stripes. Its display area size is 216.96 × 135.6 (width × Height: mm, external dimension: 229.46 × 149.1 (width × High) × 4.66 (thick) mm, with a surface treatment of Hard coating, and a net weight of 183g (Typ.).

In terms of backlight, this product adopts a 3S10P WLED side entry light source with a lifespan of 15K hours, without backlight driver. EJ101IA-01G adopts LVDS (1 ch, 8-bit) signal interface, with a total of 40 pins and terminal connections. The drive screen voltage is 2.5/8.2/12.5/13V (Typ.) (VDD/AVDD/VGH/VGL). Its typical vertical refresh rate Fv is 60Hz.

Its working temperature is -10~60°C, and its storage temperature is -20~70°C. Based on its high brightness, white LED backlight, and inverted terminals, this model is recommended for use on tablets.

Product Application:

EJ101IA-01G is 10inch Innolux lcd panel module,mainly used for HDMI tablets.At the same time, it is also widely used in various electronic products,such as Medical Equipment,Smart Home,Smart Wear,Industrial Control,Logistics Machine etc.
